14AWG 3C 19STR BC UNS CL3R/FPLR 75C GRAY

SKU: 143C

14 AWG 3C 19 STRAND BARE COPPER WIRE WITH .009" PVC INSULATION, NON-SHIELDED, OVERALL .015" GRAY PVC JACKET.

(UL) CL3R OR (UL) FPLR 75'C FT-4 SUN RES "ROHS COMPLIANT" MADE IN USA

CC: BLACK, RED, WHITE

RIPCORD: YES

FOOTAGE MARKERS: YES

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Conductor
AWG Size & Stranding	14 Awg 19 Strand
Material	Bare Copper Wire
Conductor Count	3
Insulation
Material	Polyvinylchloride
Wall Thickness	.007"
Color Code	Black, White, Red
Assembly
Nominal Lay Length	3.50”
Shield	N/A
Drain Wire	N/A
Jacket
Material	Polyvinylchloride
Wall Thickness	.015"
Diameter	0.228”
Color	Gray
Ripcord	Yes
Weight	51 lbs per mft
Nominal Diameter	0.227”
Markings
Type	Permanent Inkjet Surface Print
Legend	LAKE CABLE E171202 14AWG 3C 75C (UL) CL3R SUN RES OR FPLR FT4 “ROHS COMPLIANT” MADE IN USA
Footage Markers	Ascending/Descending
Standards
Recommended Operating Voltage	300V
Maximum operating voltage	300V
Operating Temperature Range	-20C TO 75C

Copper Price 01/29/2025 4.2405
