P123C

Not what you were looking for?

12AWG 3C 19STR BC UNS CL3P/FPLP 75C NATURAL

SKU: P123C

12 AWG 3C 19 STRAND BARE COPPER WIRE

WITH .009" SGPVC INSULATION, NON-SHIELDED,

OVERALL .015" SGPVC JACKET NATURAL.

(UL) CL3P OR FPLP 75'C FT-6 "ROHS COMPLIANT" MADE IN USA

CC: BLACK, RED, WHITE

RIPCORD: YES

FOOTAGE MARKERS: YES

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Conductor
AWG Size & Stranding	12 AWG 19 Strands Class C
Material	Bare Copper Wire
Conductor Count	3
AWG & Stranding	12 Awg 19 Strand
Insulation
Material	Plenum Rated Polyvinylchloride
Wall Thickness	.009"
Color Code	Black, White, Red
Assembly
Nominal Lay Length	3.50”
Shield	N/A
Drain Wire	N/A
Jacket
Material	Plenum Rated Polyvinylchloride
Wall Thickness	.015"
Diameter	0.264”
Color	Natural
Ripcord	Yes
Weight	80 lbs per mft
Nominal Diameter	0.262”
Markings
Type	Permanent Inkjet Surface Print
Legend	LAKE CABLE E171202 12AWG 3C 75C (UL) CL3P OR FPLP FT6 "ROHS COMPLIANT" MADE IN USA
Footage Markers	Ascending/Descending
Standards
Maximum Voltage	300V
Maximum operating voltage	300V
Operating Temperature Range	-20C TO 75C

Copper Price 12/20/2024 4.0325
